Why Infinity Lifts?
Compliance
Complies with BS6440:2011, Part M of the Building Regulations and the 2006/42/EC Machinery Directive
02
Quick Installation
This platform requires minimal building works as it is supplied with an integral ramp
03
Adaptable
A save spacing solution that can be installed inside or outside of building. Also comes with automatic gates option.
Some Snaps :)
01
170+ Years of Experience
Senior management with a combined experience of more than 160+ years.
02
Value For Money
We ensures that customers receive what they want and need with no hidden costs.
03
24/7 Assistance
Our phones are always on 24/7/365. We will always be there for you!
Why Infinity Lifts?
“As the leading Independent lift company in Ireland – our commitment to understanding the vertical transport needs of our customers has increased our focus and passion to enhance the quality of life and independence of each individual through our access for all product division”
- Garech McGuinness, CEO Infinity Lifts
Our Work Speaks For Us
.png)
“Infinity are professional, precise and a great team to work with. Their quality of workmanship, attention to detail and communication is excellent. What is truly refreshing is that I can phone Garech, Colm or any of the team and get an immediate pick up and response! I have no hesitation in recommending Infinity Lifts”.
– Bryan Quille, Monami Construction
Technical Details
Models
900mm x 1400mm
Technical Specification
Number of Floors/Travel :
Minimum travel :
Technical Compliance :
Load Capacity :
Installation :
Operation :
Power Supply :
Speed :
Operating Temperature Range :
Warranty :
Maximum travel: 3m (public access restricted to 2m).
750mm (consider our Melody 1 for lower lift height)
2006/42/EC Machinery Directive, CE Mark, BS6440 (2011) and Part M.
500kg up to 2m travel or 440kg up to 3m
Quick installation within two days. Integral ramp keeps building work to a minimum. No pit required.
Constant pressure
Dedicated 240V AC. 50 Hz. 13A single phase RCD protected supply. Battery back-up for emergency lowering.
Drive System: Direct acting hydraulic drive system
0.06 m/sec
-10 degrees Celsius to +40 degrees Celsius
12 months
1100mm x 1400mm
Technical Specification
Number of Floors/Travel :
Minimum travel :
Technical Compliance :
Load Capacity :
Installation :
Operation :
Power Supply :
Speed :
Operating Temperature Range :
Warranty :
Maximum travel: 3m (public access restricted to 2m).
750mm (consider our Melody 1 for lower lift height)
2006/42/EC Machinery Directive,
CE Mark, BS6440 (2011) and Part M.
500kg up to 2m travel or 440kg up to 3m
Quick installation within two days. Integral ramp keeps building work to a minimum. No pit required.
Constant pressure
Dedicated 240V AC. 50 Hz. 13A single phase RCD protected supply. Battery back-up for emergency lowering.
Drive System: Direct acting hydraulic drive system
0.06 m/sec
-10 degrees Celsius to +40 degrees Celsius
12 months
